VPAR-150RGBL è un proiettore LED da 150 W progettato per applicazioni architetturali versatili.
È equipaggiato con 18 LED da 20 W ciascuno, con tecnologia 4-in-1 RGBL (rosso, verde, blu, lime), che garantiscono una luminosità di 6285 lumen e un’apertura del fascio di 25°. La struttura in alluminio verniciato RAL 9002 è resistente agli agenti atmosferici, con grado di protezione IP66 e resistenza agli urti IK07. Il raffreddamento è completamente passivo, senza ventole.
Il dispositivo può funzionare in modalità stand-alone o essere controllato tramite DMX, con configurazioni da 2 a 8 canali. È compatibile con RDM attraverso un box esterno e dispone di connessioni IP67 per alimentazione e segnale. Viene fornito completo di cavo VC-Start, connettori IP e bandiere.
Vantaggi per gli utenti
- Elevata luminosità di 6285 lumen per applicazioni professionali indoor e outdoor
- Tecnologia RGBL 4-in-1 con l’aggiunta del colore Lime
- Raffreddamento passivo, silenzioso
- Classificazione IP66 e connessioni IP67 per una maggiore affidabilità in ambienti difficili
- Accessori inclusi per un’installazione immediata
Ambiti di utilizzo
- Illuminazione architetturale per edifici, facciate e monumenti
- Allestimenti scenografici per teatri, concerti e spettacoli dal vivo
- Eventi temporanei e installazioni mobili
- Ambienti commerciali come showroom, centri congressi e fiere
- Locali notturni, club e DJ set
The VPAR-150RGBL is a 150W LED projector designed for versatile architectural applications.
It is equipped with 18 x 20W LEDs, featuring 4-in-1 RGBL (red, green, blue, lime) technology, providing 6,285 lumens of brightness and a 25° beam angle. The RAL 9002 painted aluminum housing is weather-resistant, with an IP66 rating and IK07 impact resistance. It features completely passive cooling, with no fans.
The fixture can operate in standalone mode or be controlled via DMX, with configurations of 2 to 8 channels. It is RDM compatible via an external box and features IP67 connections for power and signal. It comes complete with a VC-Start cable, IP connectors, and flags.
User benefits
- High brightness of 6285 lumens for professional indoor and outdoor applications
- 4-in-1 RGBL technology with the addition of Lime color
- Passive cooling, silent operation
- IP66 rating and IP67 connections for greater reliability in harsh environments
- Included accessories for immediate installation
Areas of use
- Architectural lighting for buildings, facades, and monuments
- Scenographic installations for theaters, concerts, and live performances
- Temporary events and mobile installations
- Commercial environments such as showrooms, conference centers, and trade shows
- Nightclubs, clubs, and DJ sets
Le VPAR-150RGBL est un projecteur LED de 150 W conçu pour des applications architecturales polyvalentes.
Il est équipé de 18 LED de 20 W chacune, avec la technologie 4-en-1 RGBL (rouge, vert, bleu, lime), qui garantissent une luminosité de 6285 lumens et un angle de faisceau de 25°. La structure en aluminium peint RAL 9002 est résistante aux agents atmosphériques, avec un indice de protection IP66 et une résistance aux chocs IK07. Le refroidissement est entièrement passif, sans ventilateurs.
L'appareil peut fonctionner en mode autonome ou être contrôlé via DMX, avec des configurations de 2 à 8 canaux. Il est compatible avec RDM via un boîtier externe et dispose de connexions IP67 pour l'alimentation et le signal. Il est livré avec un câble VC-Start, des connecteurs IP et des drapeaux.
Avantages pour les utilisateurs
- Luminosité élevée de 6285 lumens pour les applications professionnelles en intérieur et en extérieur.
- Technologie RGBL 4-en-1 avec l'ajout de la couleur Lime.
- Refroidissement passif et silencieux.
- Classification IP66 et connexions IP67 pour une plus grande fiabilité dans les environnements difficiles.
- Accessoires inclus pour une installation immédiate
Domaines d'utilisation
- Éclairage architectural pour bâtiments, façades et monuments
- Décors pour théâtres, concerts et spectacles en direct
- Événements temporaires et installations mobiles
- Espaces commerciaux tels que showrooms, centres de congrès et salons
- Boîtes de nuit, clubs et DJ sets
Dati tecnici
Technical characteristics
- Power: 150 W
- LEDs: 18 x 20 W 4-in-1 LEDs (red, green, blue, lime)
- Lens opening: 25°
- Brightness: 6285 lm – 1270 lux at 5 m
- Power consumption: 153 W
- Connections: DMX / Power via hybrid IN and OUT cables with IP67 plugs
- Parameterization: VRDM-Control external box for RDM parameterization
- RDM console compatibility: yes, for basic parameters (DMX address, DMX mode, version, etc.)
- How to use :
- Stand-alone: Master/Slave and single
- DMX: 2 to 8 channels
- Macro: macros can be created for use in Master/Slave or single mode
- Power supply: 110 - 240 VAC 50-60 Hz
- Refresh rate: selectable from 900 Hz to 3600 Hz
- Cooling: convection
- Finish: cast aluminium, epoxy-painted grey-white RAL 9002
- Degree of protection: IP66 (protected against dust and splashing water)
- Shock resistance: IK07
- Pressure control: sealed diaphragm depressurization valve
- Accessories: VC-Start power cord, IP plugs, flow switch
- Dimensions: 15.7 x 26.9 x 29.1 cm
- Weight: 7 kg
